Asus - Asus ROG Strix X570-E Gaming (AMD AM4) DDR4 X570 Chipset ATX Motherboard
expand_less
expand_more
Asus - Asus ROG Strix X570-E Gaming (AMD AM4) DDR4 X570 Chipset ATX Motherboard
- Asus ROG Strix X570-E Gaming (AMD AM4) DDR4 X570 Chipset ATX Motherboard
asus

Asus ROG Strix X570-E Gaming (AMD AM4) DDR4 X570 Chipset ATX Motherboard

star_half star star star star
(4.4/5) 5 reviews
Support 3rd Gen Ryzen, Socket AM4, 8x SATA, Dual M.2, 3x PCIe 4.0x16, 2x PCIe 4.0x1, DDR4 4400 (O.C), Intel I211-AT 1 GB LAN, Intel Wi-Fi 6 AX200, Bluetooth 5.0
£299.99 (incl. VAT)
Something went wrong. We are currently working on the problem!
Pay by finance Finance available from £8.29 /month - More info
fiber_manual_record Out of stock
SKU MB-6DV-AS
EAN 4718017380515
MPN 90MB1150-M0EAY0
MANUFACTURER Asus
The Asus ROG Strix X570-E Gaming (WI-FI) is equipped to support AMD's 'Zen 2', the 3rd generation of the Ryzen Processor family.The chipset features PCIe Gen 4, giving you plenty of headroom for high speed solid state drives and supported PCIe Gen 4 graphics cards, native USB 3.1 Gen 2 ports and an overall more powerful chipset. The chipset uses active on board cooling, through the use of a mini heatsink and fan, or direct contact heat pipes (dependent on manufacturer), to ensure constant cooling delivering consistent and ultimate performance.

The Features of the Asus Asus ROG Strix X570-E Gaming at a Glance:

  • AM4 socket: Ready for 2nd and 3rd Gen AMD Ryzen™ processors to maximize connectivity and speed with up to two M.2 Drives, USB 3.2 Gen2 and AMD StoreMI
  • Aura Sync RGB: ASUS-exclusive Aura Sync RGB lighting, including RGB header and addressable Gen 2 header
  • Comprehensive cooling: Active PCH heatsink, MOS heatsink with 8mm heatpipe, dual on-board M.2 heatsinks and a water pump + header
  • Gaming connectivity: Supports PCIe 4.0, HDMI 2.0, DisplayPort 1.2 and features dual M.2 and USB 3.2 Type-A and Type-C connectors
  • Gaming networking: 2.5Gbps LAN and Intel Gigabit Ethernet with ASUS LANGuard, Wi-Fi 6 (802.11ax) with MU-MIMO, and gateway teaming via GameFirst VV
  • 5-Way Optimisation: Automated system-wide tuning, providing overclocking and cooling profiles that are tailor made for your rig
  • Gaming audio: High fidelity audio with SupremeFX S1220A, DTS® Sound Unbound and Sonic Studio III to draw you deeper into the action
  • Easy DIY: ROG-patented pre-mounted I/O shield, ASUS SafeSlot, ASUS Node connector and BIOS Flashback™ for a friendlier building experience

Specification:

  • Format:ATX
  • Chipset:AMD X570
  • Socket:
    AMD AM4 Socket for 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors



  • RAM:

    3rd Generation AMD Ryzen™ processors:
    4xDIMM,max.128GB,DDR4 4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)
    /3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/ 2666/2400/2133 MHz, un-buffered memory

    2nd Gen AMD Ryzen™ Processors:
    4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)
    /2666/2400/2133 MHz, un-buffered memory

    2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
    Dual channel memory architecture
    Refer to www.asus.com for the Memory QVL (Qualified Vendors List)



  • Graphics:

    Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors VGA output support :
    Multi-VGA output support: HDMI and DisplayPort ports
    - Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @60Hz
    - Supports DisplayPort 1.2 with maximum resolution of 4096 x 2160@60Hz



  • Multi-GPU Support:
    3rd and 2nd Gen AMD Ryzen™ Processors:
    Supports NVIDIA® 2-Way SLI™ Technology
    Supports AMD 3-Way CrossFireX™ Technology
    2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    Supports AMD 2-Way CrossFireX™ Technology
  • Storage:

    3rd Gen AMD Ryzen™ Processors :
    - 1 x M.2 Socket 3 with M Key, Type 2242/2260/2280/22110 storage devices support (PCIE 4.0 x 4 and SATA modes)

    2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    - 1 x M.2 Socket 3 with M Key, Type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 and SATA modes)

    AMD X570 chipset :
    - 1 x M.2 socket 3 with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x 4 and SATA modes) storage devices support
    - 8 x SATA 6.0 Gb/s connectors(s)
    - Support Raid 0, 1, 10



  • Slots:

    3rd Gen AMD Ryzen™ Processors:
    - 2 x PCIe 4.0 x16 SafeSlots (supports x16, x8/x8)

    2nd Gen AMD Ryzen™ Processors
    - 2 x PCIe 3.0 x16 SafeSlots (supports x16, x8/x8)

    2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    - 1 x PCIe 3.0 x16 SafeSlot (supports x8 )

    AMD X570 chipset
    - 1 x PCIe 4.0 x16 (supports x4)
    - 2 x PCIe 4.0 x 1 slots
    PCIeX16_3 slot shares bandwidth with PCIeX 1_2.



  • LAN
    Realtek RTL8125-CG 2.5G LAN
    Intel® Ethernet Controller I211-AT
    Anti-surge LANGuard
    ROG GameFirst Technology
  • Wireless Data Network
    Intel® Wi-Fi 6 AX200
    -2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with MU-MIMO supports dual frequency band 2.4/5GHz
    -Supports channel bandwidth: HT20/HT40/HT80/HT160
    -Up to 2.4 Gbps transfer speed
  • Bluetooth
    Bluetooth v5.0
  • Audio
    ROG SupremeFX 8-Channel High Definition Audio S1220A CODEC
    - Supports up to 32-Bit/192kHz playback*
    - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
    - Impedance sense for front and rear headphone outputs
    - SupremeFX Shielding Technology
    - Dual Op Amplifiers
    - Jack-detection, Multi-streaming, and Front Panel Jack-retasking
    - Optical S/PDIF out port at back panel
    Audio Features:
    - Sonic Studio III + Sonic Studio Virtual Mixer
    - Sonic Radar III
    - DTS® Sound Unbound
    Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
  • USB
    3rd Gen AMD RyzenTM Processors
     - 4 x USB 3.2 Gen2 ports (4 ports at back panel, Type-A)
    2nd Gen AMD RyzenTM/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors.
     - 4 x USB 3.2 Gen 1 ports (4 ports at back panel, Type-A)
    AMD X570 chipset
     - 1 x USB 3.2 Gen2 front panel connector
    - 4 x USB3.2 Gen2 (at back panel, 3x Type-A,1 x Type-C)
    - 2 x USB3.2 Gen1 ports (at front panel)
    - 4 x USB 2.0 ports (at front panel)
  • ROG Exclusive Features
    Digi+ VRM
    PowerIRstage
    Alloy Chokes
    5K Black Metallic Capacitors
    RAMCache III
    GameFirst V
    Sonic Studio III +Sonic Studio Virtual Mixer
    Sonic Radar III
    CPU-Z
  • Internal Connectors:

    1 x NODE connector
    1 x USB 3.2 Gen2 front panel connector
    1 x USB 3.2 Gen1 header supports additional 2 USB 3.2 Gen 1 ports
    2 x USB 2.0 connectors support additional 4 USB 2.0 ports
    1 x SPI TPM header
    8 x SATA 6Gb/s connectors
    2 x M.2 Socket 3 for M Key, type 2242/2260/2280/22110 devices (support PCIE and SATA modes)
    1 x 4-Pin CPU_FAN connector
    1 x 4-Pin CPU_OPT fan connector
    1 x 4-Pin AIO_PUMP connector
    1 x 4-Pin W_PUMP+ connector
    2 x 4-Pin CHA_FAN connectors
    1 x 4-Pin M.2_FAN connector
    1 x PCH _FAN connector
    1 x T_ SENSOR connector
    2 x AURA Addressable Gen2 headers
    2 x AURA RGB headers
    1 x 24-pin EATX power connector
    1 x 8-pin EATX 12V power connector
    1 x 4-pin EATX 12V power connector
    1 x System panel connector
    1 x Front panel audio connector (AAFP)
    1 x Clear CMOS jumper (2-pin)
  • External Connections:

    1 x HDMI port
    1 x DisplayPort
    1 x BIOS FlashbackTM button
    1 x BIOS FlashbackTM LED
    8 x USB 3.2 Gen2 ports (7 x Type-A, 1 x Type-C )
    1 x Anti-surge 2.5G LAN (RJ45) port
    1 x Anti-surge LAN (RJ45) port
    1 x 2 x 2 Wi-Fi module
    1 x Optical S/PDIF out
    5 x Gold-plated audio jacks



  • Special Features:

    ASUS Exclusive Software Features

     Armoury Crate
     AURA
     - Aura Lighting Control,Aura Addressable Gen2 Header(s), Aura RGB Strip Headers, Aura Lighting
    Effects Synchronization with compatible ASUS ROG devices
    AI Suite 3
     ASUS EZ DIY
     - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    ASUS Dual Intelligent Processors 5
     - 5-way Optimization tuning key perfectly consolidates TPU Insights, EPU Guidance, DIGI+
    VRM, Fan Expert 4, and Turbo app
    ASUS Exclusive Hardware Features
     - ROG patented pre-mounted I/O shield
    - OptiMem
    - Ai Charger
    - ASUS NODE: hardware control interface
    - BIOS FlashbackTM button
    ASUS Q-Design
     - Q-Code
    - Q-LED
    - Q-Slot
    - Q-DIMM
    Gamer's Guardian
     - DRAM Overcurrent Protection
    - ESD Guards on LAN, Audio, KBMS and USB ports
    - Highly Durable Components
    - SafeSlot
    - Procool
    - DIGI+ VRM

Specification:

  • Format:ATX
  • Chipset:AMD X570
  • Socket:
    AMD AM4 Socket for 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors



  • RAM:

    3rd Generation AMD Ryzen™ processors:
    4xDIMM,max.128GB,DDR4 4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)
    /3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/ 2666/2400/2133 MHz, un-buffered memory

    2nd Gen AMD Ryzen™ Processors:
    4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)
    /2666/2400/2133 MHz, un-buffered memory

    2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz, un-buffered memory
    Dual channel memory architecture
    Refer to www.asus.com for the Memory QVL (Qualified Vendors List)



  • Graphics:

    Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors VGA output support :
    Multi-VGA output support: HDMI and DisplayPort ports
    - Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @60Hz
    - Supports DisplayPort 1.2 with maximum resolution of 4096 x 2160@60Hz



  • Multi-GPU Support:
    3rd and 2nd Gen AMD Ryzen™ Processors:
    Supports NVIDIA® 2-Way SLI™ Technology
    Supports AMD 3-Way CrossFireX™ Technology
    2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    Supports AMD 2-Way CrossFireX™ Technology
  • Storage:

    3rd Gen AMD Ryzen™ Processors :
    - 1 x M.2 Socket 3 with M Key, Type 2242/2260/2280/22110 storage devices support (PCIE 4.0 x 4 and SATA modes)

    2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    - 1 x M.2 Socket 3 with M Key, Type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 and SATA modes)

    AMD X570 chipset :
    - 1 x M.2 socket 3 with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x 4 and SATA modes) storage devices support
    - 8 x SATA 6.0 Gb/s connectors(s)
    - Support Raid 0, 1, 10



  • Slots:

    3rd Gen AMD Ryzen™ Processors:
    - 2 x PCIe 4.0 x16 SafeSlots (supports x16, x8/x8)

    2nd Gen AMD Ryzen™ Processors
    - 2 x PCIe 3.0 x16 SafeSlots (supports x16, x8/x8)

    2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors:
    - 1 x PCIe 3.0 x16 SafeSlot (supports x8 )

    AMD X570 chipset
    - 1 x PCIe 4.0 x16 (supports x4)
    - 2 x PCIe 4.0 x 1 slots
    PCIeX16_3 slot shares bandwidth with PCIeX 1_2.



  • LAN
    Realtek RTL8125-CG 2.5G LAN
    Intel® Ethernet Controller I211-AT
    Anti-surge LANGuard
    ROG GameFirst Technology
  • Wireless Data Network
    Intel® Wi-Fi 6 AX200
    -2 x 2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with MU-MIMO supports dual frequency band 2.4/5GHz
    -Supports channel bandwidth: HT20/HT40/HT80/HT160
    -Up to 2.4 Gbps transfer speed
  • Bluetooth
    Bluetooth v5.0
  • Audio
    ROG SupremeFX 8-Channel High Definition Audio S1220A CODEC
    - Supports up to 32-Bit/192kHz playback*
    - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
    - Impedance sense for front and rear headphone outputs
    - SupremeFX Shielding Technology
    - Dual Op Amplifiers
    - Jack-detection, Multi-streaming, and Front Panel Jack-retasking
    - Optical S/PDIF out port at back panel
    Audio Features:
    - Sonic Studio III + Sonic Studio Virtual Mixer
    - Sonic Radar III
    - DTS® Sound Unbound
    Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.
  • USB
    3rd Gen AMD RyzenTM Processors
     - 4 x USB 3.2 Gen2 ports (4 ports at back panel, Type-A)
    2nd Gen AMD RyzenTM/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors.
     - 4 x USB 3.2 Gen 1 ports (4 ports at back panel, Type-A)
    AMD X570 chipset
     - 1 x USB 3.2 Gen2 front panel connector
    - 4 x USB3.2 Gen2 (at back panel, 3x Type-A,1 x Type-C)
    - 2 x USB3.2 Gen1 ports (at front panel)
    - 4 x USB 2.0 ports (at front panel)
  • ROG Exclusive Features
    Digi+ VRM
    PowerIRstage
    Alloy Chokes
    5K Black Metallic Capacitors
    RAMCache III
    GameFirst V
    Sonic Studio III +Sonic Studio Virtual Mixer
    Sonic Radar III
    CPU-Z
  • Internal Connectors:

    1 x NODE connector
    1 x USB 3.2 Gen2 front panel connector
    1 x USB 3.2 Gen1 header supports additional 2 USB 3.2 Gen 1 ports
    2 x USB 2.0 connectors support additional 4 USB 2.0 ports
    1 x SPI TPM header
    8 x SATA 6Gb/s connectors
    2 x M.2 Socket 3 for M Key, type 2242/2260/2280/22110 devices (support PCIE and SATA modes)
    1 x 4-Pin CPU_FAN connector
    1 x 4-Pin CPU_OPT fan connector
    1 x 4-Pin AIO_PUMP connector
    1 x 4-Pin W_PUMP+ connector
    2 x 4-Pin CHA_FAN connectors
    1 x 4-Pin M.2_FAN connector
    1 x PCH _FAN connector
    1 x T_ SENSOR connector
    2 x AURA Addressable Gen2 headers
    2 x AURA RGB headers
    1 x 24-pin EATX power connector
    1 x 8-pin EATX 12V power connector
    1 x 4-pin EATX 12V power connector
    1 x System panel connector
    1 x Front panel audio connector (AAFP)
    1 x Clear CMOS jumper (2-pin)
  • External Connections:

    1 x HDMI port
    1 x DisplayPort
    1 x BIOS FlashbackTM button
    1 x BIOS FlashbackTM LED
    8 x USB 3.2 Gen2 ports (7 x Type-A, 1 x Type-C )
    1 x Anti-surge 2.5G LAN (RJ45) port
    1 x Anti-surge LAN (RJ45) port
    1 x 2 x 2 Wi-Fi module
    1 x Optical S/PDIF out
    5 x Gold-plated audio jacks



  • Special Features:

    ASUS Exclusive Software Features

     Armoury Crate
     AURA
     - Aura Lighting Control,Aura Addressable Gen2 Header(s), Aura RGB Strip Headers, Aura Lighting
    Effects Synchronization with compatible ASUS ROG devices
    AI Suite 3
     ASUS EZ DIY
     - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    ASUS Dual Intelligent Processors 5
     - 5-way Optimization tuning key perfectly consolidates TPU Insights, EPU Guidance, DIGI+
    VRM, Fan Expert 4, and Turbo app
    ASUS Exclusive Hardware Features
     - ROG patented pre-mounted I/O shield
    - OptiMem
    - Ai Charger
    - ASUS NODE: hardware control interface
    - BIOS FlashbackTM button
    ASUS Q-Design
     - Q-Code
    - Q-LED
    - Q-Slot
    - Q-DIMM
    Gamer's Guardian
     - DRAM Overcurrent Protection
    - ESD Guards on LAN, Audio, KBMS and USB ports
    - Highly Durable Components
    - SafeSlot
    - Procool
    - DIGI+ VRM
Add a Review
4.4 out of 5 stars (5 reviews)

Excellent looking board!

by Tanmay B star star star star star

Excellent motherboard, a little pricey but worth it for the expandability. I liked that you can turn off the Q-Code LED after boot and set the LEDs to turn off without having to compleley poweroff the system. BIOS was easy to flash as well using a USB, but it already supported my 5800X out of the box.The EATX power cable was a bit tight but I suppose that's a good thing!

Great Motherboard!

by Benjamin Raymond star_border star star star star

Excellent board. Was really waiting for the Dark Hero version but in the end went for this one and Im glad I did as its much cheaper and has most of the same features I wanted. Installation was easy and pleased to say my 5950X was recognised immediately without having to update the BIOS. Great work ASUS. Cheers, Ben.

great motherboard

by Kate Morley star star star star star

Great Motherboard, BIOS Flashback was a saviour, good number of Ports, and good Wifi. Highly Reccommended.
Reviews are from unverified purchasers. Reviews which are factually incorrect, not related to the product, contain spam, harm, hate or profanity are not published.

UK Delivery
Order by 5pm (Monday to Friday) or 3pm (Saturday) for Next Day Delivery*
*Exclusions and product restrictions apply
Full Delivery Information

International Delivery
Delivery to over 40 countries
Full Delivery Information

Returns
30 Day return and refund period
Full Returns Information

Christmas Delivery
We recommended ordering by Friday 20th December to avoid disappointment, however we will ship Monday 23rd December.
Christmas Delivery Information

Extended Christmas Returns
All orders placed between Friday 1st November and Friday 20th December qualify for extended Christmas returns. Terms & conditions apply.
Extended Christmas Returns Information
Filter
View:
view_comfy square view_list

4.8

star star star star star_half

Google customer reviews

Our customers know our services and this is reflected in the rating they give us. Leave us your opinion and help us to improve it.

What our customers say about us

25 years trust badge
